| GB | JIS | UNS | W.Nr | ||||
| — | NW 6617 | N06617 | 2.4663 | ||||
| Executive standard | ASTM B166, AMS 5887, AMS 5888, AMS 5889, AMS 5596, AMS 5796, AMS 5715, NACE MR-01-75 | ||||||
| Surface: | Mill;HL;Polish;Mirror;NO.4;Pvd….. | ||||||
| Tchnology: | Solution Treatment；Annealing | ||||||
| MOQ: | 200KG | ||||||
| Payment Term: | T/T;L/C;WesternUnion;Paypal | ||||||
| Delivery Time: | 7-15days upon receipt of the deposit | ||||||
| Package: | Standard Expot Packing or As Customers Requirement | ||||||
| Processing form：
|
 |
 |
 |
 |
 |
||
| Ni | Co | Cr | Mn | Si | C | S | Ti | Nb+Ta | Cu | Fe | P |
| 44.556.0 | ≤
1.00 |
20.0-
24.0 |
≤
1.00 |
≤
0.50 |
≤
0.15 |
≤
0.015 |
≤
0.60 |
8.0-
10.0 |
≤
0.50 |
Bal | ≤
0.015 |
| T.S(Mpa)≥ | YS(Mpa)≥ | EL(%)≥ | HB≤ |
| 827 | 414 | 30 | 170 |
| Ni | Co | Cr | Mn | Si | C | S | Ti | Nb+Ta | Cu | Fe | P |
| 44.556.0 | ≤
1.00 |
20.0-
24.0 |
≤
1.00 |
≤
0.50 |
≤
0.15 |
≤
0.015 |
≤
0.60 |
8.0-
10.0 |
≤
0.50 |
Bal | ≤
0.015 |
| T.S(Mpa)≥ | YS(Mpa)≥ | EL(%)≥ | HB≤ |
| 827 | 414 | 30 | 170 |
Haynes 617 is a nickel-chromium-cobalt-molybdenum alloy with excellent high-temperature strength, good oxidation resistance, and excellent resistance to carburization and sulfidation. It is commonly used in gas turbine engine components, industrial furnace applications, and other high-temperature applications.
Haynes 617 has a nominal composition of 44.5% nickel, 20-24% chromium, 8-10% molybdenum, 0.5% maximum copper, 0.15% maximum carbon, 1.0% maximum cobalt, 0.5% maximum silicon, 1.0% maximum manganese, 0.015% maximum sulfur, 0.015% maximum phosphorus, and the balance iron.
Haynes 617 offers excellent mechanical properties at high temperatures, making it ideal for use in gas turbine engine components such as combustion liners, transition ducts, and exhaust systems. Its high-temperature strength and resistance to carburization and sulfidation make it suitable for use in industrial furnace applications such as radiant tubes, muffles, and retorts.
In addition to its high-temperature strength and resistance to oxidation and carburization, Haynes 617 also offers good resistance to thermal shock and thermal fatigue. This makes it ideal for use in applications that require resistance to cyclic heating and cooling, such as gas turbine engine components and industrial furnace applications.
Overall, Haynes 617 is a versatile high-temperature alloy that offers excellent mechanical properties and resistance to corrosion and oxidation in high-temperature environments. Its use in gas turbine engine components and industrial furnace applications has been well-established, and it continues to be an important material in these industries.
US standards: AMS 5887: Standard specification for Haynes 617 plate, sheet, and strip; AMS 5888: Standard specification for Haynes 617 rod, wire, and bar; AMS 5889: Standard specification for Haynes 617 seamless or welded pipe; ASME SB 166: Standard specification for Haynes 617 rod, wire, and bar; ASME SB 167: Standard specification for Haynes 617 seamless pipe; ASME SB 168: Standard specification for Haynes 617 plate, sheet, and strip; ASME SB 564: Standard specification for Haynes 617 forgings.
European standards: EN 2.4663: Standard specification for Haynes 617 plate, sheet, strip, rod, and wire; EN 10216-4: Standard specification for Haynes 617 seamless steel tubes; EN 10217-4: Standard specification for Haynes 617 welded steel tubes.
Japanese standard: JIS NW 617: Standard specification for Haynes 617 plate, sheet, strip, rod, and seamless tubes.
Chinese standard: GB/T 15006: Standard specification for Haynes 617 rod, wire, and bar; GB/T 15008: Standard specification for Haynes 617 plate, sheet, and strip; GB/T 15010: Standard specification for Haynes 617 seamless and welded tubes.
Haynes 617 alloy has a wide range of applications in high-temperature environments, particularly in gas turbine engine components, industrial furnace applications, and other high-temperature applications where excellent high-temperature strength and oxidation resistance are required. Some of its specific applications include:
Gas turbine engine components: Haynes 617 is commonly used in combustion liners, transition ducts, exhaust systems, and other high-temperature components in gas turbine engines.
Industrial furnace applications: Haynes 617 is used in a variety of industrial furnace applications, including radiant tubes, muffles, and retorts.
Heat exchangers: Haynes 617 is used in high-temperature heat exchangers for a variety of industries, including chemical processing, power generation, and oil and gas.
Petrochemical processing: Haynes 617 is used in a variety of petrochemical processing applications, including reactors, valves, and fittings.
Aerospace: Haynes 617 is used in a variety of aerospace applications, including hot sections of aircraft gas turbine engines, afterburners, and rocket engine components.
Overall, Haynes 617 is a versatile high-temperature alloy with excellent mechanical properties and resistance to oxidation and corrosion, making it suitable for use in a wide range of high-temperature applications.
Haynes 617 alloy has a wide range of applications in high-temperature environments, particularly in gas turbine engine components, industrial furnace applications, and other high-temperature applications where excellent high-temperature strength and oxidation resistance are required. Some of its specific applications include:
Gas turbine engine components: Haynes 617 is commonly used in combustion liners, transition ducts, exhaust systems, and other high-temperature components in gas turbine engines.
Industrial furnace applications: Haynes 617 is used in a variety of industrial furnace applications, including radiant tubes, muffles, and retorts.
Heat exchangers: Haynes 617 is used in high-temperature heat exchangers for a variety of industries, including chemical processing, power generation, and oil and gas.
Petrochemical processing: Haynes 617 is used in a variety of petrochemical processing applications, including reactors, valves, and fittings.
Aerospace: Haynes 617 is used in a variety of aerospace applications, including hot sections of aircraft gas turbine engines, afterburners, and rocket engine components.
Overall, Haynes 617 is a versatile high-temperature alloy with excellent mechanical properties and resistance to oxidation and corrosion, making it suitable for use in a wide range of high-temperature applications.
